Specifications:
Application: For accurate measurement and preset dispensing of diesel fuel
Measuring Principle: Positive displacement (oval gear or turbine)
Flow Range: 20–120 Liter per minute (LPM)
Accuracy: ±0.5% of reading, repeatability ±0.1%
Preset Function: Automatic shut-off at preselected volume
Display: Mechanical or electronic with batch and totalizer
Viscosity Range: Up to ~1000 cP (diesel ~2–6 cSt)
Working Pressure: Up to 10 bar (145 psi)
Temperature Range: -10°C to +60°C
Connection Size: 1" BSP
Material of Construction: Aluminum body, viton/NBR seals
Power Supply: 230V AC/12V DC/ 24V DC
Preset Control Output: Solenoid valve or pump cut-off signal
Mounting: Inline, horizontal or vertical flow
